| Electrical Characteristics | Battery Type | LFP (LiFePO4) |
| Nominal Voltage | 51.2Vdc | |
| Usable Capacity | 13.3kWh | |
| Nominal Energy | 14kWh | |
| Nominal Power | 14000W | |
| Operating Voltage | 44.8~57.6Vdc | |
| Standard Charge/Discharge Current | 140A/140A | |
| Max. Charge/Discharge Current | 200A/200A | |
| Discharge of Depth (DoD) | 95% | |
| Module Parallel | Up to 15 packs | |
| Operating Conditions | Installation Location | Outdoor / Indoor |
| Operating Temperature | Charge: 0 ~ 50℃; Discharge: -20 ~ 50℃ | |
| Installation | Wall or Floor-mounted installation | |
| Storage Temperature | -10~45℃ | |
| Humidity | 5 ~ 95 (No Condensing) | |
| Altitude | Max 2000M | |
| Communication | Communication | CAN / RS232 |
| Size and Weight | Dimension (W×D×H) | 480mm × 289mm × 960mm |
| Weight | 116±1Kg | |
| Certificate | Safety | IEC62619 / IEC62040 |
| EMC | IEC61000-6-1/3 | |
| Transportation | UN38.3 | |
| Ingress Protection | IP65 | |
| Manufacture | Production/Manufacturing Address | China |
