Modular Stacking & Easy Expansion
Adopts a building-block design that allows for flexible, tool-free capacity expansion via multi-unit parallel connection. It simplifies logistics and on-site installation, enabling users to scale their system as energy needs grow.
High-Capacity 314Ah Cells
Utilizes large-format 314Ah battery cells to reduce the number of parallel connections, lower system resistance, and achieve higher energy density.
Off-Grid & PV-Ready Integration
Features true off-grid operation with fast switchover (black start capable) to act as a primary power source during outages. Optimized for DC coupling, it maximizes self-consumption of solar energy, ensuring stable power even in weak or unstable grid environments.
Standard BMS Protocol Adaptability
Engineered for multi-brand compatibility, supporting international communication standards like Modbus, CAN. This ensures plug-and-play interoperability with leading local PCS brands and existing EMS systems.
| Item | Specification | |
| Cell | Rated Voltage (V) | 3.2 |
| Rated Energy (Ah) | 314 | |
| Cell Type | LFP | |
| Battery PACK | Rated Voltage (V) | 51.2 |
| Rated Energy (kWh) | 16.08 | |
| Cell Configuration | 1P16S | |
| Dimension (W*H*D) mm | 464*230*800 | |
| IP Rating | IP20 | |
| Battery Cabinet | Rated Voltage (V) | 819.2 |
| Voltage Range (V) | 716.8~921.6 | |
| Cluster Configuration | 1P16S-16S | |
| Rated Charge/Discharge Current (A) | 157 | |
| Rated Energy (kWh) | 257 | |
| Thermal Management | Air Cooling | |
| Fire Suppression System | Heat Detector + Smoke Detector + Aerosol | |
| Cabinet IP Rating | IP54 | |
| Working Temperature (°C) | -20~+55 | |
| Storage Temperature (°C) | 0~+45 | |
| Humidity | 0-95%RH(No condensation) | |
| Weight | 2300kg | |
| Dimension(mm) | 1200*1300*2280(W*D*H) | |
| Compatible with AC-side brands (PCS or Hybrid Inverter): Solinteg, Sinexcel, Megarevo, Hopewind, Kehua, Enjoypowers, and more... | ||
