Convenience
Quick installation with a rack-mounted design.
Quick installation with a rack-mounted design.
Flexible capacity configuration.
Intelligent BMS
Protection against over-discharge/charge, excessive discharge, and high or low temperatures.
The system automatically manages the charging and discharging states, balancing the current and voltage of each battery
Long Cycle Life
6000 cycles @ 0.5C, 25°C.
Intelligent BMS
Multiple battery modules can be connected in parallel to expand capacity and power.
| OLP-EB Indoor Series | ||||
| Cell Type | LFP | |||
| Cell Specification | 3.2V/206Ah | |||
| Battery Pack Numbers | 4 | 5 | 6 | 7 |
| Configuration | 1P96S | 1P120S | 1P144S | 1P168S |
| Rated Energy | 63.288KWh | 79.104KWh | 94.92KWh | 110KWh |
| Nominal Voltage | 307.2V | 384V | 460.8V | 537.6V |
| Voltage Range | 268.8~345.6V | 336~432V | 430.2~518.4V | 470.4~604.8V |
| Rated Current | 103A | |||
| Max. Current | 206A | |||
| Working Temperature | -20 ~ 50°C | |||
| Communication Interface | LAN/WiFi/4G | |||
| Humidity | 0~95%RH(Non-Condensing) | |||
| Altitude | ≤3000m | |||
| IP Class | IP20 | |||
| Dimensions (W*D*H) | 564*880*1260mm | 564*880*1490mm | 564*880*1720mm | 564*880*19508mm |
| Weight | 560kg | 690kg | 820kg | 950kg |
| Installation | Rack Installation | |||
| Certification | IEC62619; IEC62040; UN38.3 | |||
