High-Capacity 314Ah Cells
Large-format 314Ah cells minimize parallel connections, cut system resistance, and boost energy density for superior performance.
Off-Grid & PV-Ready
True off-grid operation with fast black-start switchover ensures primary power during outages. DC coupling maximizes solar self-consumption, delivering stable power in weak grids.
BMS Protocol Compatibility
Multi-brand ready with Modbus/CAN support, enabling plug-and-play integration with leading PCS and existing EMS systems.
Modular & Expandable
Building-block design allows tool-free, parallel capacity expansion, simplifying logistics and installation to scale with your energy needs.
| Item | Specification | |
| Cell | Rated Voltage (V) | 3.2 |
| Rated Energy (Ah) | 314 | |
| Cell Type | LFP | |
| Battery PACK | Rated Voltage (V) | 166.4 |
| Rated Energy (kWh) | 52.25 | |
| Cell Configuration | 1P52S | |
| Dimension (W*H*D) mm | 464*230*880 | |
| IP Rating | IP20 | |
| Battery Cabinet | Rated Voltage (V) | 832 |
| Voltage Range (V) | 728~936 | |
| Cluster Configuration | 1P52S-5 | |
| Rated Charge/Discharge Current (A) | 157 | |
| Rated Energy (kWh) | 261 | |
| Thermal Management | liquid cooling | |
| Fire Suppression System | Heat Detector + Smoke Detector + Aerosol | |
| Cabinet IP Rating | IP54 | |
| Working Temperature (°C) | -20~+55 | |
| Storage Temperature (°C) | 0~+45 | |
| Humidity | 0-95%RH(No condensation) | |
| Weight | 2400kg | |
| Dimension(mm) | 1000*1440*2410(W*D*H) | |
| Compatible with AC-side brands (PCS or Hybrid Inverter): Solinteg, Sinexcel, Megarevo, Hopewind, Kehua, Enjoypowers, and more... | ||
