Super Safety
Self-developed BMS, to achieve electrical protection of "Pack - Cluster - Cabinet".
Comprehensive fire detection and multiple fire protection. The entire cabinet, detected by combustible gas, smoke, temperature, and waterlogging sensor, is equipped with aerosol fire extinguishing system.
High Energy Density & Flexible Deployment
High energy density saves floor space.
Supports hoisting and forklift installation, with side-by-side and back-to-back deployment options to suit various site conditions.
Plug-and-Play & Smart Maintenance
Pre-installed and pre-commissioned at the factory for plug-and-play on site.
Supports on-line cloud monitoring, remote configuration, and OTA upgrades, reducing maintenance costs.
Wide Application, Reliable Green Power
Suitable for areas with no or insufficient power supply.
Supports peak shaving and valley filling, backup power, frequency regulation, capacity expansion, and renewable energy fluctuation smoothing, delivering stable green electricity.
| OLP-EB Indoor Series | ||||
| Cell Type | LFP | |||
| Cell Specification | 3.2V/206Ah | |||
| Battery Pack Numbers | 4 | 5 | 6 | 7 |
| Configuration | 1P96S | 1P120S | 1P144S | 1P168S |
| Rated Energy | 63.288KWh | 79.104KWh | 94.92KWh | 110KWh |
| Nominal Voltage | 307.2V | 384V | 460.8V | 537.6V |
| Voltage Range | 268.8~345.6V | 336~432V | 430.2~518.4V | 470.4~604.8V |
| Rated Current | 103A | |||
| Max. Current | 206A | |||
| Working Temperature | -20 ~ 50°C | |||
| Communication Interface | LAN/WiFi/4G | |||
| Humidity | 0~95%RH(Non-Condensing) | |||
| Altitude | ≤3000m | |||
| IP Class | IP20 | |||
| Dimensions (W*D*H) | 564*880*1260mm | 564*880*1490mm | 564*880*1720mm | 564*880*19508mm |
| Weight | 560kg | 690kg | 820kg | 950kg |
| Installation | Rack Installation | |||
| Certification | IEC62619; IEC62040; UN38.3 | |||
